Falcon Lock 25R-NL-313AN-48 Rim Exit Device Kit 512NL, 48in, Hex Dogging, Grade 1, Dark BronzeFalcon Lock 25R-NL-313AN-48 KIT is a robust rim exit device designed to meet the rigorous demands of high-traffic environments. With a single-point, rim-type latch and a sleek touch bar design, this device offers both efficiency and style. It is built with extruded aluminum for superior strength and impact resistance, ensuring long-lasting performance. Featuring a streamlined design with no exposed screws or rivets, the 25R-NL presents a clean and attractive installation. The one trim input design grants versatility, allowing for various trim options, while the stainless steel push pad cover adds a scratch-resistant surface for daily use. The device includes flush-end caps to enhance durability even in high-abuse scenarios. This non-handed exit device accommodates doors 1-3⁄4" thick, with a 3⁄4" stainless steel latchbolt throw and a standard deadlocking latchbolt for added security. Its half-turn hex dogging feature eliminates wear from threaded parts, making maintenance simpler. Certified to ANSI A156.3 grade 1 standards, the Falcon Lock 25R-NL-313AN-48 KIT is ideal for storefront applications, ensuring safety and accessibility while interfacing seamlessly with building security systems for enhanced functionality. Available in a dark bronze finish, it combines aesthetic appeal with top-notch security features.
KIT - Rim Exit Device, Nightlatch Pull Trim 512NL, 48in, Hex Dogging, Grade 1, 710/313 Dark Bronze
Notice: The info below is not item specific.
The 25-R Series rim device meets the demanding requirements of high traffic installations with a single-point, rim type latch and a streamlined touch bar design. This device can also be electrified for maximum ease of use and accessibility.
Features:
- Extruded aluminum construction delivers greater strength and impact resistance.
- No exposed screws or rivets on the back of the device for a streamlined design and clean lines for a more attractive installation.
- One trim input design provides maximum versatility and ability to use various trims.
- Stainless steel push pad cover provides a scratch-resistant pushing surface.
- Flush-end caps help prevent them from being destroyed or knocked off in abusive situations.
- Narrow stile center case is ideal for storefront applications with narrow stile aluminum doors.
Specifications:
- Hand: Non-handed.
- Strikes: 299 strike standard.
- Latchbolt: Stainless steel, 3⁄4" throw.
- Deadlocking Latchbolt: Standard.
- Dogging Feature: Half turn hex dogging standard. No threaded parts to wear out.
- Cylinder Dogging: Specify "CD" prefix. Uses 1-1⁄8" long mortise cylinder with standard cam.
- Doors: 1-3⁄4" thick, wood or metal. Specify thickness if other than 1-3⁄4".
- Projections: 2-3⁄4" maximum, 2" dogged.
- Mounting Height: 40-1⁄4" from CL to finished floor.
- Electric Functions: Can be interfaced with building security systems. Motorized electric latch retraction (fail secure only), FSA/FSE trim, security monitoring, delayed egress and exit alarm available.
- Fasteners: All mounting screws are concealed, sheet metal screws and machine screws standard.
- Sex Bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors. For EO device, specify 8 - 425 (#I0-24) SNB. For devices with trim, specify 2 - 425 (#IO-24) SNB.
- ANSI: Certified ANSI A156.3-2001 grade 1 standards.
- Center Case and Working Parts: Center case is heavy wrought and sintered metal parts.
- Shim kits: For glass lite applications; 1⁄4" thick, specify SK25-RM.
Stock Sizes:
- Single Door Application
| Device |
Door Size |
Door Strike |
Door Stile (in) |
Min. Door Opening Width |
| 25-R |
3’ |
299 |
4" |
2' 7 1⁄2" |
| 25-R |
3’ |
264 |
3 7⁄8" |
2' 7 3⁄8" |
| 25-R |
3’ |
1439 |
3 1⁄4" |
2' 6 3⁄4" |
| 25-R |
3’ |
1606 |
3 5⁄8" |
2' 7 1⁄8" |
| 25-R |
4' |
299 |
4" |
3' 1 1⁄2" |
| 25-R |
4' |
264 |
3 7⁄8" |
3' 1 3⁄8" |
| 25-R |
4' |
1439 |
3 1⁄4" |
3' 3⁄4" |
| 25-R |
4' |
1606 |
3 5⁄8" |
3' 1 1⁄8" |
- Double Door Application
| Device |
Door Size |
Strike x Mullion |
Door Stile (in.) |
Min. Door Opening Width |
| 25-R |
3’ |
299 x 2923 |
4 1⁄8" |
2' 7 1⁄2" |
| 25-R |
3’ |
299 x 4023 |
4 3⁄8" |
2' 7 1⁄2" |
| 25-R |
3’ |
264 x 2923 |
4" |
2' 7 3⁄8" |
| 25-R |
3’ |
264 x 4023 |
4 1⁄4" |
2' 7 3⁄8" |
| 25-R |
3’ |
1439 x 2923 |
3 7⁄8" |
2' 7 1⁄4" |
| 25-R |
3’ |
1439 x 4023 |
4 1⁄8" |
2' 7 1⁄4" |
| 25-R |
3’ |
1606 x 2923 |
4 1⁄4" |
2' 7 1⁄8" |
| 25-R |
3’ |
1606 x 4023 |
4 1⁄2 " |
2' 7 1⁄8" |
| 25-R |
4’ |
299 x 2923 |
4 1⁄8" |
3' 1 1⁄2" |
| 25-R |
4’ |
299 x 4023 |
4 3⁄8" |
3' 1 1⁄2" |
| 25-R |
4’ |
264 x 2923 |
4" |
3' 1 3⁄8" |
| 25-R |
4’ |
264 x 4023 |
4 1⁄4" |
3' 1 3⁄8" |
| 25-R |
4’ |
1439 x 2923 |
3 7⁄8" |
3' 1 1⁄4" |
| 25-R |
4’ |
1439 x 4023 |
4 1⁄8" |
3' 1 1⁄4" |
| 25-R |
4’ |
1606 x 2923 |
4 1⁄4" |
3' 1 1⁄8" |
| 25-R |
4’ |
1606 x 4023 |
4 1⁄2 " |
3' 1 1⁄8" |
| 25-Vx 25-R |
3’ |
1609 |
3 1⁄2" |
2' 7 5⁄8" for 3 1⁄2" Min stile |
| 25-Vx 25-R |
4’ |
1609 |
3 1⁄2" |
3’ 1 5⁄8" for 3 1⁄2" Min stile |
Finishes:
- US3/605 - Bright Brass
- US4/606 - Satin Brass
- US10/612 - Satin Bronze
- US11/643e - Aged Bronze
- US15/619 - Satin Nickel
- US19/622 - Matte Black
- US26/625- Bright Chrome
- US26D/626 - Satin Chrome
- US28/628 - Anodized Aluminum
- US32/629 - Bright Stainless Steel
- US32D/630 - Satin Stainless Steel
- 313AN/710 - Anodized Duranodic
Attributes
Ship via: Can Ship UPS
Alternate Codes: 25R-NL-313AN-48, 25RNL313AN48
Category: Panic Devices, Panic Devices & Exit Alarms, Rim Panic Devices
Certifications: A156.3, ANSI, UL 305
Device Width: 48"
Dogging: HD - Hex Dogging
Door Application: Panic Devices & Exit Alarms
Exit Device Category: Rim device
Finish Code: 313AN
Finish Color: Dark Bronze, Dark Bronze Anodized, Dark Bronze/Clear Coat, Dark Brown, Duranotic Dark Bronze
Function: Key Retracts, Night Latch
Grade: Grade 1
Manufacturer: Falcon Lock
Series: 25
Strike Type: Rim Strike, Standard
Trim Option: Night Latch, Thumbpiece Trim
