Falcon Lock 25V-EO-US3-36X96 SVR Surface Vertical Rod Exit Device, 36in, Hex Dogging, Grade 1, Bright BrassFalcon Lock 25V-EO-US3-36X96 SVR Surface Vertical Rod Exit Device offers exceptional security and ease of use for high-traffic environments. Engineered with a robust extruded aluminum construction, this exit device ensures superior strength and impact resistance, making it ideal for both panic and fire exit applications for single and double doors. The sleek surface-applied design features a standard top latch and deadlocking mechanism, providing peace of mind without compromising aesthetics. The device is designed with no exposed screws or rivets, allowing for a streamlined look that enhances any installation. A stainless steel push pad cover offers a scratch-resistant surface, while flush-end caps prevent damage in high-abuse situations. This exit device is field reversible, accommodating various door configurations and is suitable for 1-3/4" thick wood or metal doors. The half-turn hex dogging mechanism ensures reliability, with no threaded parts to wear out. Additionally, it can interface with building security systems, offering features such as motorized electric latch retraction, security monitoring, and exit alarms. Certified to ANSI A156.3 Grade 1 standards, the Falcon Lock 25V-EO-US3-36X96 is a dependable choice for ensuring safety and accessibility in commercial spaces, combining durability and functionality in one elegant package.
SVR Surface Vertical Rod Exit Device, Exit Only, 36in, Hex Dogging, Grade 1, 605/US3 Bright Brass
Notice: The info below is not item specific.
High-traffic applications demand the added strength and protection that comes with a vertical rod device. The Falcon F-25 Series delivers with a surface-applied design that includes standard top latch and deadlocking. The sleek touch bar design ensures an attractive installation.
Features:
- Extruded aluminum construction delivers greater strength and impact resistance.
- Includes panic exit and fire exit hardware for single and double door applications.
- No exposed screws or rivets on the back of the device for a streamlined design and clean lines for a more attractive installation.
- One trim input design provides maximum versatility and ability to use various trims.
- Stainless steel push pad cover provides a scratch-resistant pushing surface.
- Flush-end caps help prevent them from being destroyed or knocked off in abusive situations.
- Narrow stile center case is ideal for storefront applications with narrow stile aluminum doors.
Specifications:
- Hand: Field reversible.
- Strikes: 3788 top strike is surface applied; 2130 bottom strike is mortised into floor.
- Angle Bracket: Use 4215 angle bracket in flush transom installations. Allows use of standard 3788 strike.
- Latchbolt: Top stainless steel 3⁄4" throw. Bottom bolt, 1⁄2" throw.
- Deadlocking Latchbolt: Standard in top latch.
- Dogging Feature: Half turn hex dogging standard. No threaded parts to wear out.
- Cylinder Dogging: Specify "CD" prefix. Uses 1-1⁄8" long mortise cylinder with standard cam.
- Doors: 1-3⁄4" thick, wood or metal. Specify thickness if other than 1-3⁄4".
- Projections: 2-3⁄4" maximum, 2" dogged.
- Electric Features: Can be interfaced with building security systems. Motorized electric latch retraction (fail secure only), FSA/FSE trim, security monitoring, delayed egress and exit alarm available.
- Fasteners: All mounting screws are concealed, sheet metal screws and machine screws available, specify AMS.
- Sex Bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors. For EO device, specify 12 - 425 (#10-24) SNB. For devices with trim, specify 8 - 425 (#10-24) SNB.
- ANSI: Certified ANSI A156.3-2001 grade 1 standards.
- Vertical Rods: Furnished to length based on a 40-1⁄4" horizontal CL from finished floor and a 7’ 0" door standard. Variations from these standards must be specified when ordering.
- 25-V-LBR: Less bottom rod vertical device.
- Shim Kits: For glass lite applications; 1⁄4" thick, specify SK25-V.
Stock Sizes:
| Device |
Door Size |
Door Strike |
Min. Stile (In.) |
Min. Door Opening Width |
| 25-V |
3’ |
All |
3-1/2" |
2’ 7-1/8" |
| 25-V |
4’ |
All |
3-1/2" |
3’ 1-1/8" |
| 25-V x 25-R |
3’ |
1609 |
3-1/2" |
2’ 7-5/8" for 3-1/2" Min. Stile |
| 25-V x 25-R |
4’ |
1609 |
3-1/2" |
2’ 1-5/8" for 3-1/2" Min. Stile |
Finishes:
- 605/US3 - Brass, Bright
- 606/US4 - Brass, Satin
- 612/US10 - Bronze, Satin
- 619/US15 - Nickel, Satin
- 622/US19 - Black, Matte
- 625/US26 - Chromium, Bright
- 626/US26D - Chromium, Satin
- 629/US32 - Stainless Steel, Bright
- 630/US32D - Stainless Steel, Satin
- 628/US28 - Anodized Aluminum
- 643e/US11 - Bronze, Aged
- 71-0/313AN - Anodized Duranodic
Attributes
Ship via: Can Ship UPS
Alternate Codes: 25V-EO-US3-36X96, 25VEOUS336X96
Category: Panic Devices, Panic Devices & Exit Alarms, SVR Panic Devices
Certifications: A156.3, ANSI, UL 305
Device Width: 36"
Dogging: HD - Hex Dogging
Door Application: Panic Devices & Exit Alarms
Exit Device Category: Surface vertical rod
Finish Code: US3
Finish Color: Polished Brass
Function: Exit Only
Grade: Grade 1
Manufacturer: Falcon Lock
Rod Extension: 12"
Series: 25
Strike Type: Vertical Rod Bottom Strike, Vertical Rod Top Strike
