Falcon Lock 25V-TP-US3-36X96 KIT - SVR Surface Vertical Rod Exit Device, Thumbpiece Pull Trim, Polished BrassFalcon Lock 25V-TP-US3-36X96 KIT is a robust solution designed for high-traffic environments where security and durability are paramount. This surface vertical rod exit device features a thumbpiece pull trim and is constructed from extruded aluminum, delivering enhanced strength and resistance to impact. Its sleek design, free of exposed screws or rivets, ensures a streamlined appearance that complements any setting. Engineered with safety in mind, this exit device includes panic and fire exit hardware suitable for both single and double door applications. The top latch features a deadlocking mechanism, while the innovative half-turn hex dogging provides reliable operation without wear-prone threaded parts. The stainless steel push pad cover offers a scratch-resistant surface, and flush-end caps are included to withstand abusive conditions. The Falcon Lock 25V also accommodates doors with a thickness of 1-3/4", ensuring compatibility with wood or metal doors. Its field-reversible hand allows for versatile installation, while the device is certified to meet ANSI A156.3 grade 1 standards. With electric features available for integration with building security systems, this exit device is an ideal choice for commercial settings looking for a blend of security, functionality, and aesthetic appeal.
KIT - SVR Surface Vertical Rod Exit Device, Thumbpiece Pull Trim 512TP, 36in x 96in, Hex Dogging, Left Hand Reverse/Reversible, Grade 1, 605/US3 Polished Brass
Notice: The info below is not item specific.
High-traffic applications demand the added strength and protection that comes with a vertical rod device. The Falcon F-25 Series delivers with a surface-applied design that includes standard top latch and deadlocking. The sleek touch bar design ensures an attractive installation.
Features:
- Extruded aluminum construction delivers greater strength and impact resistance.
- Includes panic exit and fire exit hardware for single and double door applications.
- No exposed screws or rivets on the back of the device for a streamlined design and clean lines for a more attractive installation.
- One trim input design provides maximum versatility and ability to use various trims.
- Stainless steel push pad cover provides a scratch-resistant pushing surface.
- Flush-end caps help prevent them from being destroyed or knocked off in abusive situations.
- Narrow stile center case is ideal for storefront applications with narrow stile aluminum doors.
Specifications:
- Hand: Field reversible.
- Strikes: 3788 top strike is surface applied; 2130 bottom strike is mortised into floor.
- Angle Bracket: Use 4215 angle bracket in flush transom installations. Allows use of standard 3788 strike.
- Latchbolt: Top stainless steel 3⁄4" throw. Bottom bolt, 1⁄2" throw.
- Deadlocking Latchbolt: Standard in top latch.
- Dogging Feature: Half turn hex dogging standard. No threaded parts to wear out.
- Cylinder Dogging: Specify "CD" prefix. Uses 1-1⁄8" long mortise cylinder with standard cam.
- Doors: 1-3⁄4" thick, wood or metal. Specify thickness if other than 1-3⁄4".
- Projections: 2-3⁄4" maximum, 2" dogged.
- Electric Features: Can be interfaced with building security systems. Motorized electric latch retraction (fail secure only), FSA/FSE trim, security monitoring, delayed egress and exit alarm available.
- Fasteners: All mounting screws are concealed, sheet metal screws and machine screws available, specify AMS.
- Sex Bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors. For EO device, specify 12 - 425 (#10-24) SNB. For devices with trim, specify 8 - 425 (#10-24) SNB.
- ANSI: Certified ANSI A156.3-2001 grade 1 standards.
- Vertical Rods: Furnished to length based on a 40-1⁄4" horizontal CL from finished floor and a 7’ 0" door standard. Variations from these standards must be specified when ordering.
- 25-V-LBR: Less bottom rod vertical device.
- Shim Kits: For glass lite applications; 1⁄4" thick, specify SK25-V.
Stock Sizes:
| Device |
Door Size |
Door Strike |
Min. Stile (In.) |
Min. Door Opening Width |
| 25-V |
3’ |
All |
3-1/2" |
2’ 7-1/8" |
| 25-V |
4’ |
All |
3-1/2" |
3’ 1-1/8" |
| 25-V x 25-R |
3’ |
1609 |
3-1/2" |
2’ 7-5/8" for 3-1/2" Min. Stile |
| 25-V x 25-R |
4’ |
1609 |
3-1/2" |
2’ 1-5/8" for 3-1/2" Min. Stile |
Finishes:
- 605/US3 - Brass, Bright
- 606/US4 - Brass, Satin
- 612/US10 - Bronze, Satin
- 619/US15 - Nickel, Satin
- 622/US19 - Black, Matte
- 625/US26 - Chromium, Bright
- 626/US26D - Chromium, Satin
- 629/US32 - Stainless Steel, Bright
- 630/US32D - Stainless Steel, Satin
- 628/US28 - Anodized Aluminum
- 643e/US11 - Bronze, Aged
- 71-0/313AN - Anodized Duranodic
Attributes
Ship via: No UPS - Common Carrier Only
Alternate Codes: 25V-TP-US3-36X96, 25VTPUS336X96
Category: Panic Devices, Panic Devices & Exit Alarms, SVR Panic Devices
Certifications: A156.3, ANSI, UL 305
Device Width: 36"
Dogging: HD - Hex Dogging
Door Application: Panic Devices & Exit Alarms
Exit Device Category: Surface vertical rod
Finish Code: US3
Finish Color: Polished Brass
Function: Thumbpiece
Grade: Grade 1
Manufacturer: Falcon Lock
Rod Extension: 12"
Series: 25
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Strike Type: Vertical Rod Bottom Strike, Vertical Rod Top Strike
Trim Option: Night Latch, Thumbpiece Trim
