Falcon Lock RX-25R-L-DAN-US3-36-RHR RX Request to Exit Rim Device, Dane Lever Trim 510L, Polished Brass, Grade 1Falcon Lock RX-25R-L-DAN-US3-36-RHR KIT features a robust rim exit device designed to meet the rigorous demands of high-traffic environments. With a sleek touch bar design and a durable extruded aluminum construction, this device provides exceptional strength and impact resistance, ensuring long-lasting performance even in demanding conditions. This model includes a stainless steel push pad cover, delivering a scratch-resistant surface for easy operation. The hex dogging mechanism is user-friendly and eliminates the wear associated with threaded components. Its non-handed design allows for flexible installation, accommodating various door types with a thickness of 1-3/4 inches, while the narrow stile center case makes it ideal for storefront applications. Certified to ANSI A156.3 grade 1 standards, the RX-25R is not only reliable but also versatile, able to interface with building security systems for electric functions. The polished brass finish adds a touch of elegance, enhancing the overall aesthetic of your installation. With a 299 strike standard and a 3/4-inch stainless steel latchbolt, this exit device ensures secure and efficient egress. Choose the Falcon Lock RX-25R-L-DAN-US3-36-RHR KIT for a perfect blend of security, design, and functionality in your building projects.
KIT - RX Request to Exit, Rim Exit Device, Escutcheon x Dane Lever Trim 510L, 36in, Hex Dogging, RHR Right Hand Reverse/Reversible Handing, 299 Strike, Grade 1, 605/US3 Polished Brass
Notice: The info below is not item specific.
The 25-R Series rim device meets the demanding requirements of high traffic installations with a single-point, rim type latch and a streamlined touch bar design. This device can also be electrified for maximum ease of use and accessibility.
Features:
- Extruded aluminum construction delivers greater strength and impact resistance.
- No exposed screws or rivets on the back of the device for a streamlined design and clean lines for a more attractive installation.
- One trim input design provides maximum versatility and ability to use various trims.
- Stainless steel push pad cover provides a scratch-resistant pushing surface.
- Flush-end caps help prevent them from being destroyed or knocked off in abusive situations.
- Narrow stile center case is ideal for storefront applications with narrow stile aluminum doors.
Specifications:
- Hand: Non-handed.
- Strikes: 299 strike standard.
- Latchbolt: Stainless steel, 3⁄4" throw.
- Deadlocking Latchbolt: Standard.
- Dogging Feature: Half turn hex dogging standard. No threaded parts to wear out.
- Cylinder Dogging: Specify "CD" prefix. Uses 1-1⁄8" long mortise cylinder with standard cam.
- Doors: 1-3⁄4" thick, wood or metal. Specify thickness if other than 1-3⁄4".
- Projections: 2-3⁄4" maximum, 2" dogged.
- Mounting Height: 40-1⁄4" from CL to finished floor.
- Electric Functions: Can be interfaced with building security systems. Motorized electric latch retraction (fail secure only), FSA/FSE trim, security monitoring, delayed egress and exit alarm available.
- Fasteners: All mounting screws are concealed, sheet metal screws and machine screws standard.
- Sex Bolts: Recommended when device is used with hollow core wood, composite or light gauge hollow metal doors. For EO device, specify 8 - 425 (#I0-24) SNB. For devices with trim, specify 2 - 425 (#IO-24) SNB.
- ANSI: Certified ANSI A156.3-2001 grade 1 standards.
- Center Case and Working Parts: Center case is heavy wrought and sintered metal parts.
- Shim kits: For glass lite applications; 1⁄4" thick, specify SK25-RM.
Stock Sizes:
- Single Door Application:
| Device |
Door Size |
Door Strike |
Door Stile (in) |
Min Door Opening Width |
| 25-R |
3’ |
299 |
4" |
2' 7 1⁄2" |
| 25-R |
3’ |
264 |
3 7⁄8" |
2' 7 3⁄8" |
| 25-R |
3’ |
1439 |
3 1⁄4" |
2' 6 3⁄4" |
| 25-R |
3’ |
1606 |
3 5⁄8" |
2' 7 1⁄8" |
| 25-R |
4' |
299 |
4" |
3' 1 1⁄2" |
| 25-R |
4' |
264 |
3 7⁄8" |
3' 1 3⁄8" |
| 25-R |
4' |
1439 |
3 1⁄4" |
3' 3⁄4" |
| 25-R |
4' |
1606 |
3 5⁄8" |
3' 1 1⁄8" |
- Double Door Application:
| Device |
Door Size |
Strike x Mullion |
Door Stile (in) |
Min Door Opening Width |
| 25-R |
3’ |
299 x 2923 |
4 1⁄8" |
2' 7 1⁄2" |
| 25-R |
3’ |
299 x 4023 |
4 3⁄8" |
2' 7 1⁄2" |
| 25-R |
3’ |
264 x 2923 |
4" |
2' 7 3⁄8" |
| 25-R |
3’ |
264 x 4023 |
4 1⁄4" |
2' 7 3⁄8" |
| 25-R |
3’ |
1439 x 2923 |
3 7⁄8" |
2' 7 1⁄4" |
| 25-R |
3’ |
1439 x 4023 |
4 1⁄8" |
2' 7 1⁄4" |
| 25-R |
3’ |
1606 x 2923 |
4 1⁄4" |
2' 7 1⁄8" |
| 25-R |
3’ |
1606 x 4023 |
4 1⁄2 " |
2' 7 1⁄8" |
| 25-R |
4’ |
299 x 2923 |
4 1⁄8" |
3' 1 1⁄2" |
| 25-R |
4’ |
299 x 4023 |
4 3⁄8" |
3' 1 1⁄2" |
| 25-R |
4’ |
264 x 2923 |
4" |
3' 1 3⁄8" |
| 25-R |
4’ |
264 x 4023 |
4 1⁄4" |
3' 1 3⁄8" |
| 25-R |
4’ |
1439 x 2923 |
3 7⁄8" |
3' 1 1⁄4" |
| 25-R |
4’ |
1439 x 4023 |
4 1⁄8" |
3' 1 1⁄4" |
| 25-R |
4’ |
1606 x 2923 |
4 1⁄4" |
3' 1 1⁄8" |
| 25-R |
4’ |
1606 x 4023 |
4 1⁄2 " |
3' 1 1⁄8" |
| 25-Vx 25-R |
3’ |
1609 |
3 1⁄2" |
2' 7 5⁄8" for 3 1⁄2" Min stile |
| 25-Vx 25-R |
4’ |
1609 |
3 1⁄2" |
3’ 1 5⁄8" for 3 1⁄2" Min stile |
Finishes:
- US3/605 - Brass, Bright
- US4/606 - Brass, Satin
- US1-0/612 - Bronze, Satin
- US1-1/643e - Bronze, Aged
- US1-5/619 - Nickel, Satin
- US1-9/622 - Black, Matte
- US2-6/625 - Chromium, Bright
- US26D/626 - Chromium, Satin
- US2-8/628 - Anodized, Aluminum
- US3-2/629 - Stainless Steel, Bright
- US32D/630 - Stainless Steel, Satin
- 313AN/710 - Anodized Duranodic
Attributes
Ship via: Can Ship UPS
Access Type: Request to Exit
Alternate Codes: RX-25R-L-DAN-US3-36-RHR, RX25RLDANUS336RHR
Category: Electrified Panic Devices, Panic Devices & Exit Alarms
Certifications: A156.3, ANSI, UL 305
Device Width: 36"
Dogging: HD - Hex Dogging
Door And Lock Sensor: Pushbar Monitor
Door Application: Panic Devices & Exit Alarms
Exit Device Category: Rim device
Finish Code: US3
Finish Color: Polished Brass
Function: Dane Standard, Lever
Grade: Grade 1
Handing: Right Handed Reverse
Lever Design: Dane
Manufacturer: Falcon Lock
Series: 25
Strike Type: Rim Strike, Standard
Trim Option: Lever Trim
